PACKAGE SUBSTATIONS (PSS)
Compact, Safe & Ready-to-Install Power Distribution Solutions
Integrated Power Distribution Systems up to 36 kV
Tecksons Package Substations (PSS), also known as Unitized Substations, are factory-assembled and factory-tested power distribution solutions that combine Medium Voltage Switchgear, Distribution Transformer, and Low Voltage Switchboard into a single compact enclosure.
Designed for utilities, infrastructure projects, industrial facilities, commercial developments, renewable energy installations, and urban distribution networks, our package substations provide a safe, space-efficient, and cost-effective alternative to conventional substations.
What is a Package Substation?
A Package Substation is a prefabricated electrical substation in which all major power distribution components are integrated into a single enclosure and delivered as a complete ready-to-install unit.
Medium Voltage Section
- Ring Main Unit (RMU)
- Vacuum Circuit Breaker (VCB) Panels
- Load Break Switches
- Protection & Metering Equipment
Transformer Section
- Oil Filled Distribution Transformer
- Hermetically Sealed Transformer
- Conservator Type Transformer
- Inverter Duty Transformer (for Solar Applications)
Low Voltage Section
- Main Distribution Board
- Incoming & Outgoing Feeders
- Metering & Protection Devices
- Capacitor Bank (Optional)
Key Advantages
Plug-and-Play Solution
Factory assembled and tested before dispatch.
Fast Installation
Minimal site work and reduced commissioning time.
Compact Design
Ideal for space-constrained urban and industrial environments.
Enhanced Safety
Segregated compartments with internal safety interlocks.
Reduced Civil Costs
Requires significantly less site infrastructure compared to conventional substations.
Reliable Performance
Factory-controlled assembly ensures consistent quality.
Easy Maintenance
Accessible design with clear compartment segregation.
Future Ready
Can be customized for renewable energy and smart grid applications.
Technical Specifications
| Parameter | Capability |
|---|---|
| System Voltage | Up to 36 kV |
| Transformer Rating | Up to 3.15 MVA (Higher ratings on request) |
| Frequency | 50 Hz / 60 Hz |
| Cooling | ONAN |
| Transformer Type | Oil Filled / Hermetically Sealed |
| Protection Degree | Up to IP54 |
| Insulation Level | As per IEC Standards |
| Enclosure Material | CRCA / Galvanized Steel |
| Finish | Powder Coated / Special Outdoor Paint System |
Applications
Utilities
- Urban Power Distribution
- Residential Colonies
- Utility Expansion Projects
Renewable Energy
- Solar Power Plants
- Rooftop Solar Installations
- Battery Energy Storage Systems (BESS)
Infrastructure Projects
- Airports
- Metro Rail Systems
- Railway Stations
- Smart Cities
- Water Treatment Plants
Commercial Developments
- Shopping Malls
- IT Parks
- Hospitals
- Educational Institutions
- High-Rise Buildings
Industrial Applications
- Manufacturing Plants
- Warehouses
- Logistics Parks
- Process Industries
Design Features
Compact Footprint
Optimized layout for maximum space utilization.
Segregated Compartments
Separate MV, Transformer, and LV sections for improved safety.
Ventilation System
Designed for effective heat dissipation.
Corrosion Protection
Suitable for coastal and high-humidity environments.
Arc Fault Considerations
Enhanced safety features for personnel protection.
Customizable Configurations
Tailored to utility, industrial, and renewable energy requirements.
Manufacturing Excellence
Every Package Substation is manufactured under strict quality control procedures using modern production facilities.
Infrastructure Highlights
- Advanced Transformer Manufacturing Facility
- LV Foil Winding Machine
- PLC Controlled Bus Bar Cutting, Punching & Bending Machine
- Precision Fabrication Facility
- Modern Testing Laboratory
- Vacuum Oil Processing Systems
- Experienced Engineering Team
Export Capability
- High Ambient Temperatures
- Desert Conditions
- Coastal Environments
- Utility-Specific Requirements
- GCC Specifications
Why Choose Tecksons Package Substations?
Integrated Engineering
Single-source responsibility for transformer, switchgear, and LV systems.
Proven Manufacturing Capability
Decades of experience in transformer and power distribution equipment manufacturing.
Reduced Project Timelines
Factory-built solutions minimize site activities.
Cost Effective
Lower installation, civil, and commissioning costs.
Customized Solutions
Designed to suit project-specific requirements.
Reliable Performance
Built using quality components and tested before dispatch.
Complete Power Distribution Solutions
Tecksons Package Substations
